Epson launched new printhead I1600-A1 --Suitable for DTF printer market
Original: Aug 23, 2023 | Updated: Jul 2026 | By AGP Printer Technical Team
Quick answer: The Epson I1600-A1 is a PrecisionCore MicroTFP water-based printhead with 1,600 nozzles (4 rows × 400) that produces native 600 dpi output at a price positioned between the entry-level F1080 and the premium I3200-A1. It matches the I3200-A1's printing precision and service life, but costs roughly half as much per nozzle — which is why most new 60cm DTF printers now use four I1600-A1 heads instead of two I3200-A1 heads, gaining up to 80% faster print speed at a similar total cost.
- What it is: Epson's mid-tier PrecisionCore printhead, released to fill the gap between F1080 and I3200-A1.
- Best for: Water-based DTF, DTG, textile and sublimation printers, typically 30cm–60cm print width.
- Key advantage: I3200-A1-level accuracy and lifespan, at a lower entry cost — ideal for 4-head high-speed configurations.
- Not ideal for: Ultra-budget desktop printers (F1080 is cheaper) or single-head max-precision setups where I3200-A1 already fits the budget.
What Is the Epson I1600-A1 Printhead?
The Epson I1600-A1 is a cost-effective, 1.33-inch-wide MEMS printhead built on Epson's PrecisionCore Micro TFP (Thin Film Piezo) platform. It was launched to sit between two printheads that already dominated the DTF printer market: the budget F1080 and the high-end I3200-A1. Because it shares the same manufacturing process and nozzle precision as the I3200-A1, the I1600-A1 delivers comparable image quality and durability, just with half the nozzle count and a correspondingly lower price.
Since launch, the I1600-A1 has become a standard component in mid-to-high-volume DTF, DTG, textile and sublimation printers, and is now widely stocked by printhead suppliers worldwide (Kingdom DTF, DTF Bank, Digiprint USA, Orca Coatings, and others), which confirms its position as an established, mainstream printhead rather than a niche option.
How Does the I1600-A1 Compare to the F1080 and I3200-A1?
Choosing a printhead is really a trade-off between three variables: price, precision, and lifespan. Here's how the three most common DTF printheads stack up:
| Comparison Point | F1080 | I1600-A1 | I3200-A1 |
|---|---|---|---|
| Market position | Entry-level | Mid-range | High-end |
| Purchase cost | Lowest | Medium | Highest |
| Printing accuracy | Lower | High (same as I3200-A1) | High |
| Service life | Shorter | Long (same as I3200-A1) | Long |
| Typical print width fit | ≤ 30cm | 30cm – 60cm | ≥ 60cm |
| Best suited to | Small-format desktop printers | Mid-volume shops wanting I3200-level quality at lower cost | Large-format, high-volume production |
In short: the F1080 is the cheapest but wears out faster and is limited to small formats. The I3200-A1 offers top-tier speed and accuracy but at a premium price, and usually only makes sense on 60cm+ machines. The I1600-A1 fills the middle ground — same physical print quality and lifespan as the I3200-A1, at a friendlier price point.
What Technology Makes the I1600-A1 Different?
1. PrecisionCore MEMS Technology
MEMS manufacturing and thin-film piezo technology give the I1600-A1 high nozzle density in a compact package, enabling fast, high-quality printing. Epson's proprietary MEMS nozzle and ink flow-path design keeps ink droplets round, accurate, and consistent — reducing banding and mis-registration issues common with lower-grade heads.
2. Grayscale Support (VSDT)
Epson's Variable Sized Droplet Technology (VSDT) lets the printhead fire droplets of different volumes, producing smooth tonal gradations rather than harsh dithering — important for photo-quality DTF transfers.
3. High Native Resolution
The I1600-A1 fires up to 4 ink colors at 600 dpi (2 interleaved rows of 300 dpi each), matching the resolution class of the I3200-A1 and giving customers a second high-quality option beyond Epson's original I3200 lineup.
4. Industrial-Grade Durability
Because the I1600-A1 shares its core PrecisionCore architecture with Epson's industrial print engines, it inherits the same durability and extended service life — a major reason it can compete directly with the I3200-A1 despite its lower price.
Which DTF Printers Use the I1600-A1 Printhead?
AGP has developed a dedicated series of DTF printer configurations built specifically around the I1600-A1, alongside our existing I3200-A1 machines. The most popular configuration is our 60cm four-head I1600-A1 DTF printer, priced similarly to a two-head I3200-A1 machine, but delivering roughly 80% faster print speed — a significant productivity gain for shops scaling up production.
We'll be publishing a detailed technical breakdown comparing I1600-A1 and I3200-A1 configurations across our AGP and TEXTEK series machines in an upcoming article — covering configuration, ink capacity, and cost-per-print advantages of each.
Epson I1600-A1 Technical Specifications
| Specification | Detail |
|---|---|
| Model | Epson I1600-A1 |
| Technology | PrecisionCore Micro TFP (Thin Film Piezo) MEMS |
| Ink type | Aqueous / water-based (DTF, DTG, textile, sublimation) |
| Total nozzles | 1,600 (4 rows × 400 nozzles) |
| Nozzle resolution | 300 npi per row / 600 npi combined (2 rows) |
| Max ink channels / colors | 4 |
| Effective print width | 33.8mm (1.33 in.) |
| Dimensions (W×D×H) | 69.1 × 59.4 × 35.6 mm |
| Weight | 80g |
| Ink viscosity range | 3–4 mPa·s |
| Droplet technology | Variable Sized Droplet Technology (VSDT) — grayscale capable |
| Positioning | Reference-hole mechanism |
Note: nozzle-count, dimension, and viscosity figures above are drawn from Epson's published printhead specifications and are consistent across major DTF suppliers. Firing-frequency and drop-size figures vary slightly by driver/firmware configuration — confirm with your printer manufacturer for machine-specific values.
Is the I1600-A1 Worth Upgrading To?
If you're currently running F1080 heads and finding their lifespan or print quality is limiting your business, the I1600-A1 is a natural upgrade path — same accuracy and durability class as the I3200-A1, without the full premium price. If you're comparing it against the I3200-A1 for a new 60cm+ machine, the deciding factor is usually speed-per-dollar: a four-head I1600-A1 setup can out-produce a two-head I3200-A1 setup at a similar investment level, making it the stronger choice for shops prioritizing throughput.
