| Model |
UV-2513 |
| Printhead |
Ricoh Gen 5/Gen 6(7PL)Grey Scale Micro Piezo Printhead |
| Printhead No. |
2-8H |
| Ukuran Print |
2500mm * 1300mm |
| Ketebalan Print |
1mm-100mm |
| Tipe Tinta |
Ramah lingkungan UV Curing Ink |
| Warna Tinta |
Standar: C M Y K Lc Lm W, Varnish opsional |
| Kacepetan Cetak (8H-Kabeh Werna) |
Mode Kacepetan Dhuwur: 56.7m²/h;
Mode Produksi: 34.2m²/h;
Mode Kualitas Tinggi: 29.2m²/h |
| Piranti lunak RIP |
Standar: PhotoPrint. Pabrik Print lan Onyx opsional. |
| Sistem Pasokan Tinta |
Sistem Pasokan Tinta Tekanan Negatif Otomatis |
| Sistem Monitoring Tinta |
Voice Intelligent Alarm System |
| Jinis Media |
Akrilik, Papan Aluminium, Ubin Keramik, Kaca, Papan Kayu, PC, TPU, Kulit, Papan PVC, dll. |
| Sistem Adsorpsi Media |
4 Zona Vakum, Kasedhiya kanggo Macem-macem Jinis Media |
| Fungsi Lifting |
Imbuhan Otomatis Dhuwur Carriage, Deteksi Cerdas Kekandelan Material |
| Piranti Ventilasi |
Ventilasi Fan Perlu. Volume Exhaust Udara: 600 CFM |
| Format File Cetak |
TIFF, JPEG, PDF, EPS, PNG, AI, BMP, lsp. |
| Daya/Daya Rating |
220V 50HZ/60HZ/8.0KW |
| Konfigurasi Komputer |
Sistem Komputer: Win10, 64 bit, Port USB 2.0 |
| Lingkungan Kerja |
Independen, Resik, Lebu Kurang, Kurang Sunshine, Bengkel Ventilasi Inggih;
Suhu: 15°C-28°C; Kelembapan: 40% -70% |
| Ukuran Mesin/Bobot |
4206 * 2200 * 1500mm (L * W * H) 1300kg |
| Ukuran Kemasan/Bobot |
4400 * 2300 * 1750mm (L * W * H) 1600kg |
